SC(JGK) COPPER CABLE LUG WITH CHECKING HOLE

Type	φ	D	d	L
SC(JGK)-1.5	φ4.2,φ5.2	3.5	1.8	18
SC(JGK)-2.5	φ4.2,φ5.2,φ6.2	4	2.5	19
SC(JGK)-4	φ5.2,φ6.2	4.8	3.1	21
SC(JGK)-6	φ5.2,φ6.2,φ8.2	5.5	3.8	24
SC(JGK)-10	φ6.2,φ8.2	6.8	4.8	25.5
SC(JGK)-16	φ6.2,φ8.2,φ10.5	7.5	5.5	30.5
SC(JGK)-25	φ6.2,φ8.2,φ10.5	9	7	34
SC(JGK)-35	φ6.2,φ8.2,φ10.5,φ12.5	10.5	8.2	38
SC(JGK)-50	φ8.2,φ10.5,φ12.5	12.5	9.8	46.5
SC(JGK)-70	φ8.2,φ10.5,φ12.5	14.5	11.5	49
SC(JGK)-95	φ10.5,φ12.5	17.5	13.8	55
SC(JGK)-120	φ12.5,φ16.5	19.5	15.5	64.5
SC(JGK)-150	φ12.5,φ16.5	21	16.5	67
SC(JGK)-185	φ16.5	23.5	18.8	78
SC(JGK)-240	φ16.5	26.5	21	84
SC(JGK)-300	φ16.5,φ20.5	30	24	94
SC(JGK)-400	φ16.5,φ20.5	34	26.5	109
SC(JGK)-500	φ16.5,φ20.5	38	30	123
SC(JGK)-630	φ20.5	45	35	135
SC(JGK)-800	φ22.5	50	39	170
SC(JGK)-1000	φ22.5	56	44	200
